Aerocool Trinity V3 Mini ITX Case - Black

AEROCOOL TRINITY G-BK-V3 Mini ITX Case - Black

MINI TOWER CASE

Designed with ventilation in mind, this case delivers superior air flow while allowing for viewing of your front LED fans. This high-performance mini tower case comes equipped with a full tempered glass side panel to showcase the inside of your rig. Supports liquid cooling in the front and rear of the case for maximum efficiency cooling.

IMPROVED AIR VENTILATION

Stylish front panel design with built-in air vents delivers increased air flow and ventilation while allowing for viewing of your front LED fans.

FULL TEMPERED GLASS SIDE PANEL

Comes equipped with a full tempered glass side panel to showcase the inside of your rig and put your components on display.

COOLING FOR YOUR GRAPHICS CARD

Fan mounts on the PSU shroud support graphics card cooling : 2 x 120mm fans for superior VGA cooling.

AIR COOLING

Supports air cooling in the front, top, and rear of the case to enhance cooling performance.

• Front: 120mm x 2 or 140mm x 2 (Max.)
• Top: 120mm x 2 (Max.)
• Rear: 120mm x 1 (Max.)
• PSU Shroud: 120mm x 2 (Max.)

LIQUID COOLING

Supports liquid cooling in the front and rear of the case for maximum efficiency cooling.

• Front: 120/240mm Radiator (Optional)  (for 240mm, supports max length of 240mm and max thickness of 28mm)
• Rear: 120mm Radiator (Optional)

DUAL CHAMBER DESIGN

Built with a dual chamber design to direct heat away from the main chamber for more effective all-around cooling.

BUILT FOR HIGH PERFORMANCE

• Supports Micro-ATX and mini-ITX motherboards
• Supports CPU coolers up to 158mm
• Supports high-end graphics cards up to 297mm (without front radiator)

CONVENIENT ACCESS TO YOUR MEDIA

Quick and easy access to USB 3.0 x 2, USB 2.0 x 1, HD audio and mic ports, and power & reset button.

STORAGE CAPABILITY

Supports up to 2 x 3.5 HDDs (2 x 3.5/2.5³) and 3 x 2.5” SSDs (1 x 2.5 and 2 x 2.5/3.5).

Specifications

• Model : Trinity Mini
• Case Type : Mini Tower
• Color : Black
• Body Material : SPCC
• Front Panel Material : ABS
• Steel Thickness : 0.5mm
• Motherboards : Micro ATX/mini-ITX
• Case Dimensions (Internal) : 200 x 375 x 300mm (W x H x D)
• Case Dimensions (Overall) : 206.5 x 385 x 353.4mm (W x H x D)
• 3.5 Drive Bays : 2 Max. (2 x 3.5/2.5)
• 2.5 Drive Bays : 3 Max. (1 x 2.5 and 2 x 2.5/3.5)
• Expansion Slots : 4
• GPU Clearance : Supports GPU up to 297mm (without front radiator)
• CPU Cooler Clearance : Supports CPU cooler up to 158mm
• Air Cooling : Front: 120mm x 2 or 140mm x 2 (Max.)

                                 Top: 120mm x 2 (Max.)

                                 Rear: 120mm x 1 (Max.)

                                 PSU Shroud: 120mm x 2 (Max.)

• Liquid Cooling : Front: 120/240mm Radiator (Optional)

                                     (for 240mm, supports max thickness of 28mm)

                                      Rear: 120mm Radiator (Optional)

• I/O Ports : USB3.0 x 2 | USB2.0 x 1 | HD Audio & Mic.
• Internal Cable Management Depth : 20.5mm
• Power Supply : ATX PSU (Including cables, up to 159mm) (Optional)
• EAN Code : Trinity Mini-G-BK-v3: 4710562758634 (includes: 14cm RGB fan x 2, 12cm RGB fan x 1)
