ASUS ROG STRIX HELIOS GX601 ARGB Mid Tower Case - White
Brand
Acer
- Premium design & aesthetics: Made for showcase builds with three tempered-glass panels, brushed-aluminum frame and integrated Aura Sync RGB front lighting
- Clean build made easy: A multifunction cover with graphics card holders, a PSU shroud and a translucent rear cable cover offer effortless cable management
- Versatile GPU mounting: Install three graphics cards in standard orientation, or two vertically for extra showcase flair using a bundled bracket
- Ready for serious cooling: Supports an up to EATX motherboard, with room for 420mm front radiators and water-cooling pump and reservoir
- Advanced I/O panel: USB 3.1 Gen 2 Type-C port, four USB 3.0 ports, an RGB-lighting control button and a fan-speed control button
- Comfortable case handles: Easily carry your prized build to LAN parties with ergonomic and stylish fabric handles
Categories:
ASUS ROG Strix Helios GX601 White Edition RGB Mid-Tower Computer Case
ROG Strix Helios White Edition is a premium mid-tower gaming case with three tempered-glass panels, a silver-white aluminum frame and integrated front-panel RGB lighting. Built-in cable management, including a multifunction cover with GPU braces, keeps the interior sharp and tidy. Engineered for expandability and performance, it's ready for an up to EATX motherboard and serious water-cooling setups - making it the perfect choice for a unique white ROG showcase build.
PREMIUM DESIGN & WHITE AESTHETICS
ROG Strix Helios White Edition is made to go with your clean white components for a stunning showcase build. With three smoked tempered-glass panels fitted in a silver-white brushed-aluminum frame, and dynamic RGB lighting integrated into the front of the case, ROG Strix Helios White Edition will make your setup stand out from the pack.
AURA SYNC RGB LIGHTING
Featuring integrated addressable RGB LEDs in the front panel that can be customized using a dedicated control button or with Aura software, ROG Strix Helios White Edition can cast millions of colors and a range of effects that can be synchronized with a vast ecosystem of components to augment your build.
* Note that some lighting effects require the ASUS Aura software and vary by model. Default case I/O panel lighting controls: Static, Breathing, Strobing and Rainbow.
UNIQUE MULTI-FUNCTION COVERS DESIGN
An adjustable smart multi-function cover to suit both ATX and EATX motherboard. While it helps to hide the cable and holes for a neat presentation, there is also dedicated space to mount the ROG Terminal. There is additional GPU holder that secures the graphics cards in place like a pair of chopstick for the enhanced security of heavy graphics cards during transportation.
TEMPERED GLASS LATCH OPEN DOOR DESIGN
Featuring 3x 4mm-thick smoked tempered-glass on both sides and the front.
Tool-less assembly with quick release latch button together with bottom mount bracket design to assure safety.
GRAPHICS CARD PLACEMENT OPTIONS
Horizontal mounted up to three graphics cards. The additional stand up PCIe slots and the exclusive GPU bracket enables you to show off up to two graphics cards in the vertical position.
* Riser cables sold separately
COOLING COMPATIBILITY
Fan:
Top: 3x120 / 2x140mm
Front: 3x120 or 140mm
Rear: 1x120 or 140mm
Radiator:
Top: 120 / 140 / 240 / 280 / 360mm
Front: 120 / 140 / 240 / 280 / 360 / 420mm
Rear: 120 / 140mm
STRONG, COMFORTABLE CARRY HANDLES
It's ergonomic design, easy and safe to transport to LAN parties or gaming events with the integrated fabric carry handles.
Rigorously tested to support up to 110 pounds (50kg).
PSU SHROUD WITH CUT-OUT DESIGN
Unique ROG Cyber text Pattern & two-pieces design of PSU shroud allows for removable first shroud for additional clearance to mount thicker radiator.
The special front cut-out to showcase with ROG Strix 850W White Edition or other OLED integrated power supplies.
Specifications
- Case Size : Mid Tower
- Motherboard Support : EATX (12"x10.9"), ATX, Micro-ATX, Mini-ITX
- Drive Bays : 4 x 2.5" Bay, 2 x 2.5"/3.5" Combo Bay
- Expansion Slots : 8, 2 (additional vertical)
- Maximum Cable Management Space : 33 mm
- Dimensions : 250 x 565 x 591 mm
- Weight : 18Kg
- Maximum CPU Cooler Height : 190 mm
- Maximum GPU Length : 450 mm (Riser Cable above 200mm in length is required for one GPU install in vertical position)
- Maximum PSU Length : 220 mm
- Pre-installed Fans (Front) : 3 x 140 mm
- Pre-installed Fans (Rear) : 1 x 140 mm
Front I/O Port
- 1 x Headphone
- 1 x Microphone
- 4 x USB 3.1 Gen1
- 1 x USB 3.1 Gen2 Type C
- LED Control Button
- Fan Control Button
- Reset Button
Tempered Glass
- Front Side
- Left Side
- Right Side
Radiator Support (Front)
- 120 mm
- 140 mm
- 240 mm
- 280 mm
- 360 mm
- 420 mm
Radiator Support (Top)
- 120 mm
- 140 mm
- 240 mm
- 280 mm
- 360 mm
Radiator Support (Rear)
- 120 mm
- 140 mm
Cooling Support (Front)
- 3 x 120 mm
- 3 x 140 mm
- Radiator + Fan Thickness: Max. 90 mm
Cooling Support (Top)
- 3 x 120 mm
- 2 x 140 mm
- Radiator + Fan Thickness: Max. 60 mm
Cooling Support (Rear)
- 1 x 120 mm
- 1 x 140 mm
Removable Dust Filters
