ASUS ROG STRIX RTX 4090 24GB BTF GAMING Graphics Card - Black

ASUS ROG STRIX NVIDIA GEFORCE RTX 4090 24GB GDDR6X BTF DLSS3 Graphics Card - Black

The ROG Strix GeForce RTX™ 4090 BTF Edition brings a whole new meaning to going with the flow.

Inside and out, every element of the card gives the monstrous GPU headroom to breathe freely and achieve ultimate performance.

The unleashed reign of the NVIDIA Ada Lovelace architecture is here.

Advanced BTF Design

With the combination of a BTF graphics card, motherboard and chassis, you can enjoy a full hidden-connector experience. This Advanced BTF approach is achieved through the new graphics card high-power slot available on BTF motherboards, which can deliver up to 600 watts to BTF graphics cards. With a full set of BTF components, builders can eliminate visible cables for an extra-clean aesthetic.

Axial-tech Upgrades

A Fresh Spin

Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 23% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.

Reverse Rotation and 0dB Technology

Orchestrated Chill

The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55°C, referencing a speed curve that balances performance and acoustics for work or play.

3.5-slot Design

Through Thick and Fin

The custom sink is generously sized and structured to soak up heat from the GeForce RTX 4090 BTF GPU so that it can be efficiently whisked away by the three Axial-tech fans.

Patented Vapor Chamber

Phase Changer

A vapor chamber featuring milled pathways lets the heatpipes sink in without being pressed flat, allowing heat to be carried more efficiently to the fin stack. In comparison to conventional vapor chamber and heatpipe combos, this potent pairing reduces GPU temperature by up to 5 Celsius when subjected to a 500W thermal load.

Premium Power Delivery

1st Responder

Digital power control, an array of high-current power stages, and a lineup of 15K caps ensure massive reserves to reliably push performance boundaries.

Compact PCB

Packs a Punch

Component and trace layouts have been optimized onto a short PCB to reduce power losses and let heat escape through a massive backplate vent.

Metal Exoskeleton

Ultra-rigid

A high-quality diecast frame, shroud, and backplate tightly brace the PCB and strategically steer airflow.

Go With The Flow

It all comes together to effortlessly drive GeForce RTX™ 4090 BTF Edition performance to the max.

Graphics Card High-Power (GC-HPWR) Gold Finger

A Clutter-Free Future

The graphics card high-power (GC-HPWR) gold finger is capable to deliver up to 600W through the “graphics card high-power slot” on BTF motherboards, eliminating visible external power connectors for a cleaner build. This design also adds structural support, preventing graphics card sag and ensuring a sleek setup.

FanConnect II

Hook up

Two PWM FanConnect headers provide additional DIY flexibility. Chassis fans can be directly attached to the card and tuned with a curve that is based on CPU and GPU temperatures, delivering extra intake or exhaust for demanding 3D tasks.

Reinforcements

Additional Perks

A GPU bracket provides extra stability to the critical connection between die and heat spreader. The rear I/O bracket is made from stainless steel to prevent corrosion in humid climates and provide a more resilient mount. A conveniently placed Dual Bios switch allows quick selection between “performance” and “quiet” speed profiles for the Axial-tech fans.

Auto-Extreme Technology

Reliability Boost

Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.

Aura Sync

Symphony of Light

Aura-compatible ARGB lighting elements on the shroud and rightmost perimeter of the card provide endless possibilities for personalization with color or functional effects. Pair up with a vast range of compatible system components and coordinate the glow to create a build that’s uniquely you.

Graphics Card Holder

Pillar of Support

The bundled graphics card holder banishes sag and also contains a screwdriver to help you build.

Specifications

• Graphic Engine : NVIDIA® GeForce RTX™ 4090
• AI Performance : 1321
• Bus Standard : PCI Express 4.0
• OpenGL : OpenGL®4.6
• Video Memory : 24GB GDDR6X
• Engine Clock : OC mode: 2550 MHz
• Default mode: 2520 MHz (Boost clock)
• CUDA Core : 16384
• Memory Speed : 21 Gbps
• Memory Interface : 384-bit
• Resolution : Digital Max Resolution 7680 x 4320
• Interface : Yes x 2 (Native HDMI 2.1a)

                                Yes x 3 (Native DisplayPort 1.4a)

                                HDCP Support Yes (2.3)

• Maximum Display Support : 4
• NVlink/ Crossfire Support : No
• Accessories : 1 x Collection Card​

                                        1 x Speedsetup Manual​

                                        1 x ROG Graphics Card Holder

                                        1 x ROG Velcro Hook & Loop

                                        1 x Thank you Card

• Software : ASUS GPU Tweak III & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
• Dimensions : 357.6 x 149.3 x 70.1mm
• Recommended PSU : 1000W
• Power Connectors : No
• Slot : 3.5 Slot
• AURA SYNC : ARGB
• Hidden-connector (BTF) : With Graphics card high-power gold finger

Note

• * BTF edition graphics cards are designed for use only with advanced BTF motherboards (which have Graphics Card High-Power Slot).
• * Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html
• * All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. If you do not use the latest and current specifications of ASUS products, you shall be liable for all loss and damage claimed by third party to ASUS based on false advertising or any other issues caused from using false specifications of ASUS products.
