GIGABYTE NVIDIA GEFORCE RTX 2060 GDDR6 12GB Graphics Card - Black
Brand
Acer- Powered by GeForce RTX 2060
- Integrated with 12GB GDDR6 192-bit memory interface
- WINDFORCE 2X Cooling System with alternate spinning fans
- 90mm unique blade fans
- Protection back plate
- Core Clock : 1650 MHz
Categories:
GIGABYTE NVIDIA GEFORCE RTX 2060 GDDR6 12GB Graphics Card - Black
WINDFORCE 2X COOLING SYSTEM
WINDFORCE 2X cooling system features two 90mm unique blade fans, alternate spinning, one composite copper heat pipe direct touches the GPU and 3D active fans, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
ALTERNATE SPINNING
The GIGABYTE Alternate Spinning is the only solution that can solve the turbulent airflow of adjacent fans. Since the adjacent fans rotate in the same direction, the airflow direction is opposite between the fans, which will cause turbulent airflow and reduce heat dissipation efficiency. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
HEAT PIPE DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU, enhancing heat transfer. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
COMPOSITE HEAT-PIPE
The composite heat-pipe combines thermal conductivity and phase transition to efficiently manage the heat transfer between two solid interfaces which increases cooling capacity.
BUILT STRONG
EXTREME DURABILITY
The graphics card uses the better power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.
Protection Back Plate
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
IN TOTAL COMMAND
The actual software UI and functionalities depend on each device model.
AORUS Engine
The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your games requirements.
Specifications
- Graphics Processing : GeForce RTX 2060
- Core Clock : 1650 MHz
- RTX-OPS : 40
- CUDA® Cores : 2176
- Memory Clock : 14000 MHz
- Memory Size : 12 GB
- Memory Type : GDDR6
- Memory Bus : 192 bit
- Memory Bandwidth (GB/sec) : up to 336 GB/s
- Card Bus : PCI-E 3.0 x 16
- Digital max resolution : 7680x4320
- Multi-view : 4
- Card size : L=224 W=121 H=41 mm
- PCB Form : ATX
- DirectX : 12
- OpenGL : 4.6
- Recommended PSU : 550W
- Power Connectors : 8 Pin*1
- Output
DisplayPort 1.4 *3
HDMI 2.0b *1
- SLI Support : N/A
- Accessories : Manual
