INTEL CORE i7 14700KF 33M Cache Up To 5.60 GHz - Processor

INTEL CORE i7-14700KF 20-Core LGA 1700 14th Gen Processor

Power up your productivity, gaming, and content creation with the Intel Core i7-14700KF 3.4 GHz 20-Core LGA 1700 Processor. Built with the Intel 7 process, this 14th generation desktop processor delivers improved power efficiency while fitting the LGA 1700 socket. Featuring an optimized Hybrid Core Architecture, the Core i7-14700KF powers demanding applications and games with eight 3.4 GHz Performance-cores while the 12 low-voltage Efficient-cores handle background tasks for smooth multitasking. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.

With 30MB of cache and a 5.6 GHz Turbo Boost Max 3.0 frequency, this processor is made to handle intense workloads. You can overclock this processor for even greater performance. The Core i7-14700KF also supports PCI Express 5.0 and up to 192GB of dual-channel DDR5 memory at 5600 MHz.

The Core i7-14700KF does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. Please note that a thermal solution is NOT included. This processor is backed by a 3-year warranty.

Hybrid Core Design

Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks such as streaming video, playing music, and encoding media are handled by the processor's Efficient-cores.

Intel Thread Director

The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 28 threads are assigned to the right core at the right time.

PCIe 4.0 & 5.0

This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.

Gaussian & Neural Accelerator 3.0

Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.

Intel Deep Learning Boost

Accelerates AI inference to improve performance for deep learning workloads.

Specifications

Essentials

• Product Collection : Intel® Core™ i7 Processors (14th gen)
• Code Name : Products formerly RAPTOR LAKE
• Vertical Segment : Desktop
• Processor Number : i7-14700KF
• Lithography : Intel 7
• Use Conditions : PC/Client/Tablet

CPU Specifications

• Total Cores : 20
• # of Performance-cores : 8
• # of Efficient-cores : 12
• Total Threads : 28
• Max Turbo Frequency : 5.6 GHz
• Intel® Turbo Boost Max Technology 3.0 Frequency : 5.6 GHz
• Performance-core Max Turbo Frequency : 5.5 GHz
• Efficient-core Max Turbo Frequency : 4.3 GHz
• Performance-core Base Frequency : 3.4 GHz
• Efficient-core Base Frequency : 2.5 GHz
• Cache : 33 MB Intel® Smart Cache
• Total L2 Cache : 28 MB
• Processor Base Power : 125 W
• Maximum Turbo Power : 253 W

Supplemental Information

• Embedded Options Available : No

Memory Specifications

• Max Memory Size (dependent on memory type) : 192 GB
• Memory Types : Up to DDR5 5600 MT/s

                                    Up to DDR4 3200 MT/s

• Max # of Memory Channels : 2
• Max Memory Bandwidth : 89.6 GB/s

Expansion Options

• Direct Media Interface (DMI) Revision : 4.0
• Max # of DMI Lanes : 8
• Scalability : 1S Only
• PCI Express Revision : 5.0 and 4.0
• PCI Express Configurations  : Up to 1x16+4, 2x8+4
• Max # of PCI Express Lanes : 20

Package Specifications

• Sockets Supported : FCLGA1700
• Max CPU Configuration : 1
• Thermal Solution Specification  : PCG 2020A
• TJUNCTION : 100°C
• Package Size : 45.0 mm x 37.5 mm

Advanced Technologies

• Intel® Gaussian & Neural Accelerator : 3.0
• Intel® Thread Director : Yes
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
• Intel® Speed Shift Technology : Yes
• Intel® Turbo Boost Max Technology 3.0 : Yes
• Intel® Turbo Boost Technology  : 2.0
• Intel® Hyper-Threading Technology : Yes
• Intel® 64 : Yes
• Instruction Set : 64-bit
• Instruction Set Extensions : Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
• Idle States : Yes
• Enhanced Intel SpeedStep® Technology : Yes
• Thermal Monitoring Technologies : Yes
• Intel® Volume Management Device (VMD) : Yes

Security & Reliability

• Intel® Standard Manageability (ISM) : Yes
• Intel® Control-Flow Enforcement Technology : Yes
• Intel® AES New Instructions : Yes
• Secure Key : Yes
• Intel® OS Guard : Yes
• Execute Disable Bit : Yes
• Intel® Boot Guard : Yes
• Mode-based Execute Control (MBEC) : Yes
• Intel® Virtualization Technology (VT-x) : Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
• Intel® VT-x with Extended Page Tables (EPT) : Yes
