MSI PRO B760M-P DDR5 Motherboard - Black

MSI PRO B760M-P DDR5 mATX Motherboard

PRO B760M-P DDR5 is designed with tons of flexible tools with DDR5 memory version.

The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.

HARDWARE

power solution

Cooling Overview

msi PRO B760M-P DDR5 cooling overview mobile

    M.2 Shield Frozr

    Strengthened M.2 thermal solution helps keep M.2 SSD safe and ensures incredible performance.

    Chipset Heatsink

    The chipset heatsink is designed to reduce dust and noise and also capable of maintaining high efficiency of PCH.

CORE BOOST

Core Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.

PERFORMANCE

Expansion

Lightning Gen 4 PCI-e with Steel Armor

Doubling over the previous generation, the bandwidth of a x16 interface can reach 64GB/s.

Memory

DDR5 Memory Solution

With MSI Memory Boost technology and premium layout design, MSI PRO Series motherboards are ready to deliver the world-class memory performance.

Bios & software

MSI brand new MSI Center unifies a suite of MSI software utilities into a single centralized application. Take control of advanced motherboards features and unleash endless possibilities.

Connectivity

EXTEND YOUR RGB EXPERIENCE WITH EASE

Add more color if you want! Mystic Light Extension pin header provides an intuitive way to control additional RGB strips and other RGB peripherals added to a system, without needing a separate RGB controller.

Specifications:-

Chipset

• INTEL B760

CPU SUPPORT

• Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
• LGA 1700

Memory

• 4x DDR5, Maximum Memory Capacity 192GB
• Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
• Max. overclocking frequency:
• • 1DPC 1R Max speed up to 6800+ MHz
• • 1DPC 2R Max speed up to 6400+ MHz
• • 2DPC 1R Max speed up to 6000+ MHz
• • 2DPC 2R Max speed up to 5600+ MHz
• Supports Intel® XMP 3.0 OC
• Supports Dual-Controller Dual-Channel mode
• Supports non-ECC, un-buffered memory

Onboard Graphics

• 1x HDMI™
• Support HDMI™ 1.4, maximum resolution of 4K 30Hz*
• 1x DisplayPort
• Support DP 1.4, maximum resolution of 4K 60Hz*
• 1x VGA
• Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz

EXPANSION SLOT

• 1x PCI-E x16 slot
• 2x PCI-E x1 slot
• PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
• PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset)
• PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset)

Storage

• 2x M.2
• M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
• M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
• 4x SATA 6G

RAID

• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

USB

• 4x USB 2.0 (Rear)
• 4x USB 2.0 (Front)
• 1x USB 3.2 Gen1 Type A (Rear)
• 2x USB 3.2 Gen1 Type A (Front)
• 1x USB 3.2 Gen2 Type C (Rear)

LAN

• Realtek® RTL8111H Gigabit LAN

Audio

• Realtek® ALC897 Codec
• 7.1-Channel High Definition Audio

Internal I/O

• 1x Power Connector(ATX_PWR)
• 1x Power Connector(CPU_PWR)
• 1x CPU Fan
• 2x System Fan
• 2x Front Panel (JFP)
• 1x Chassis Intrusion (JCI)
• 1x Front Audio (JAUD)
• 1x Printer Port (JLPT)
• 1x Com Port (JCOM)
• 1x RGB LED connector(JRGB)
• 1x TPM pin header(Support TPM 2.0)
• 4x USB 2.0 ports
• 2x USB 3.2 Gen1 Type A ports

LED FEATURE

• 4x EZ Debug LED

BACK PANEL PORTS

• VGA
• DisplayPort
• HDMI™
• Keyboard / Mouse
• USB 2.0
• LAN port
• Audio Connectors
• USB 3.2 Gen 1 5Gbps (Type-A)
• USB 3.2 Gen 2 10Gbps (Type-C)

OPERATING SYSTEM

• Support for Windows® 11 64-bit, Windows® 10 64-bit

PCB Dimension

• mATX
• 243.84mmx243.84mm
