ASUS ROG LOKI SFX-L 850W PLATINIUM Fully Modular GEN 5.0 Power Supply - Black
Brand
Acer![Acer Acer](https://q8quadra.com/media/magiccart/shopbrand/brand/a/c/acer.png)
Wattage : 850W
Fully Modular Cables
80 Plus Platinum
Fan Size : 120mm
90YE00N3-B0NA00
Categories:
ASUS ROG LOKI SFX-L 850W PLATINIUM Fully Modular GEN 5.0 Power Supply Unit - Black
ROG Loki 850W Platinum
The Quietest SFX-L PSU
Taking after the ROG Thor, the ROG Loki SFX-L 850W Platinum brandishes the same enthusiast-grade components and features, all packed into an SFX-L form factor. Boasting quiet operation and high performance, the Loki is primed to power your next SFF build.
COOLING
ROG Heatsinks
Cool under pressure
ROG heatsinks facilitate lower temperatures, longer component lifespan, and extended 0dB operation.
ENGINEERING
80 PLUS Platinum Certified
Effortless output
Low-ESR Japanese capacitors further improve efficiency and reduce heat, readying ROG Loki to reliably fuel your build for years to come.
EXPERIENCE
ARGB-illuminated Fan & Aura Sync
Magical glow
The Loki's 120 mm fan features eight addressable LEDs ready to be customized with Aura Sync to create coordinated lighting patterns across your build.
Specifications
- Intel Form Factor : SFX-L
- ATX 3.0 : Yes
- Dimensions : 125 x 125 x 63.5 mm
- Efficiency : 80Plus Platinum
- Protection Features : OPP/OVP/UVP/SCP/OCP/OTP
- Hazardous Materials : ROHS
- AC Input Range : 100-240Vac
- DC Output Voltage : +3.3V +5V +12V -12V +5Vsb
- Maximum Load : 20A 20A 70.8A 0.8A 2.5A
- Combined Load : 110W 110W 850W 9.6W 12.5W
- Total Output : 850W
- Connector : MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 PCI-E 8-pin x 3 SATA x 6 PERIPHERAL x 4
- Package Contents : Power Cord x 1 Motherboard Power Cable x 1 (450mm) CPU Cable x 2 (550mm) PCI-E Gen 5 16-pin Cable x 1 (450mm) PCI-E 1-to-1 Cable x 1 (450mm) PCI-E 1-to-2 Cable x 1 (450mm) SATA 1-to-3 Cable x 2 (300+200+100mm) Peripheral 1-to-4 Cable x 1 (300+100+100+100mm) Addressable RGB Cable x 1 (800mm) User Manual x 1 ATX to SFX adapter bracket x 1
- Weight : 1.815kg (single PSU)
- AURA SYNC : ARGB
- 0dB Fan Button : No
- Cybenetics Noise Level Certification : A
