ASUS TUF Gaming 750W 80 Plus Gold Fully modular Power Supply - Black
Brand
Acer
- Capacitors and chokes pass demanding tests to achieve Military-grade Certification.
- Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
- A protective PCB coating protects against moisture, dust, and extreme temperatures.
- An 80 Plus Gold Certification is the result of Japanese capacitors and other premium components.
- Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure.
- Fully modular etched cables keep your rig neat and tidy.
Categories:
ASUS TUF GAMING 750W - 80 Plus Gold Fully Modular Power Supply - Black
The TUF Gaming 750W Gold is an efficient, resilient and dependable PSU that’s engineered for the long haul.
Specifications
- Model : TUF Gaming 750W Gold
- Intel Form Factor : ATX12V
- ATX 3.0 : Yes
- Dimensions : 150 x 150 x 86 mm
- Efficiency : 80Plus Gold
- Protection Features : OPP/OVP/UVP/SCP/OCP/OTP
- Hazardous Materials : ROHS
- AC Input Range : 100-240Vac
- DC Output Voltage : +3.3V +5V +12V -12V +5Vsb
- Maximum Load : 25A25A62A 0.8A 3A
- Combined Load : 130W 744W 9.6W 15W
- Total Output : 750W
- Connectors : MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 16-pin x 1
PCI-E 8-pin x 3
SATA x 5
PERIPHERAL x 4
- Package Contents : Power Cord x 1
Motherboard Power Cable x 1 (610mm)
CPU Cable x 2 (650mm)
PCI-E Gen 5 16-pin Cable x 1 (675mm)
PCI-E 1-to-1 Cable x 1 (675mm)
PCI-E 1-to-2 Cable x 1 (675mm)
SATA 1-to-2 Cable x 1 (400+120mm)
SATA 1-to-3 Cable x 1 (400+120+120mm)
Peripheral 1-to-4 Cable x 1 (400+150+150+150mm)
TUF Gaming Cable tie x 3
User Manual x 1
- Weight : 2.38kg (single PSU)
- 0dB Fan Button : No
