FSP HYDRO PTM X PRO 1200W 80 Plus Platinum 12VHPWR Connector PCIe 5.0 Power Supply - White
Brand
Acer
Complies with ATX12V V3.0 & EPS12V V2.92
Efficiency ≧ 92% at typical load
Active PFC ≧ 0.9
450V, 105°C Japanese bulk capacitors
Japanese electrolytic capacitors
Industrial-grade design with conformal coating application
+12V single-rail design
+5V & 3.3V DC to DC module design
Eco semi-fanless fan control switch
120mm fluid dynamic bearing (FDB) fan
Fully modular cabling design
Changeable side stickers for DIY enthusiasts and gamers
Complete protection: OCP/OVP/OPP/SCP/OTP
Categories:
FSP HYDRO PTM X PRO 1200W - 80 Plus Platinum Fully Modular Gen 5.0 Power Supply Unit - White
New ATX PSU Specifications
Updated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.
High Power Density
Compared to general high-efficiency & high wattage PSU 190mm length, the Hydro PTM X PRO series delivers over 1200W with shorter size of 130mm.
ECO Switch, Quieter and Longer Lasting Fan
Under 30% loading, you will enjoy 0 BA experience when eco semi-fanless fan control switch is on.
Exclusive Conformal Coating
Covered with exclusive conformal coating protects it from dust, stains, humidity and guarantees to offer better and reliable performance in harsh environments.
LLC Half Bridge Topology
Zero voltage switching of the main switches thereby dramatically lowering switching losses and boosting efficiency.
450V, 105°C Japanese Bulk Capacitors
Hydro PTM X PRO series uses Japanese Bulk capacitors to ensure a longer lifetime and protect your PSU from sudden power change.
80 Plus® Platinum Certification
Hydro PTM X PRO series is a power supply with 80 PLUS® Platinum provides over 92% efficiency at the load of 50 % and reduces electricity cost.
Powerful +12V Single Rail for your VGA
Hydro PTM X PRO series offers VGA cards full & stable power individually and to avoid any overloading conditions.
Fully Modular Design with Black Flat Cable
Fully-modular design not just for easier installation, but also provides your system a neat and tidy look.
Stylish & Changeable Side Sticker
Includes unique side stickers for DIY enthusiasts and gamers.
Specifications
- Model : HPT3-1200M,Gen5 (White Edition)
- Rated Output Power : 1200W
- Form Factor : ATX
- 80 PLUS Certification : Platinum
- Input Voltage : 100-240V
- Input Current : 14-9A
- Input Frequency : 50-60Hz
- PFC : Active PFC
- Efficiency : 92% at typical load
- Fan Type : FDB fan, 120mm
- Dimensions(L x W x H) : 130×150×86 mm
- Protection : OCP, OVP, OPP, SCP, OTP
